Startup configuration

Depending on the use-case, the Ankaios cluster can be started with an optional predefined list of workloads - the startup configuration. Currently the startup configuration is provided as a file which is in YAML file format and can be passed to the Ankaios server through a command line argument. If Ankaios is started without or with an empty startup configuration, workloads can still be added to the cluster dynamically during runtime.

Note: To be able to run a workload an Ankaios agent must be started on the same or on a different node.

Configuration structure

The startup configuration is composed of a list of workload specifications within the workloads object. A workload specification must contain the following information:

  • workload name(via field key), specify the workload name to identify the workload in the Ankaios system.
  • runtime, specify the type of the runtime. Currently supported values are podman and podman-kube.
  • agent, specify the name of the owning agent which is going to execute the workload. Supports templated strings.
  • restartPolicy, specify how the workload should be restarted upon exiting.
  • tags, specify a list of key value pairs.
  • runtimeConfig, specify as a string the configuration for the runtime whose configuration structure is specific for each runtime, e.g., for podman runtime the PodmanRuntimeConfig is used. Supports templated strings.
  • configs: assign configuration items defined in the state's configs field to the workload
  • controlInterfaceAccess, specify the access rights of the workload for the control interface.

Example startup-config.yaml file:

apiVersion: v0.1
workloads:
  nginx: # this is used as the workload name which is 'nginx'
    runtime: podman
    agent: agent_A
    restartPolicy: ALWAYS
    tags:
      - key: owner
        value: Ankaios team
    configs:
      port: web_server_port
    runtimeConfig: |
      image: docker.io/nginx:latest
      commandOptions: ["-p", "{{port.access_port}}:80"]
    controlInterfaceAccess:
      allowRules:
      - type: StateRule
        operation: Read
        filterMask:
        - "workloadStates"
configs:
  web_server_port:
    access_port: "8081"

Ankaios supports templated strings and essential control directives in the handlebars templating language for the following workload fields:

  • agent
  • runtimeConfig

Ankaios renders a templated state at startup or when the state is updated. The rendering replaces the templated strings with the configuration items associated with each workload. The configuration items themselves are defined in a configs field, which contains several key-value pairs. The key specifies the name of the configuration item and the value is a string, list or associative data structure. To see templated workload configurations in action, see the tutorial Manage a fleet of vehicles from the cloud.

Note

The name of a configuration item can only contain regular characters, digits, the "-" and "_" symbols. The same applies to the keys and values of the workload's configs field when assigning configuration items to a workload.

PodmanRuntimeConfig

The runtime configuration for the podman runtime is specified as follows:

generalOptions: [<comma>, <separated>, <options>]
image: <registry>/<image name>:<version>
commandOptions: [<comma>, <separated>, <options>]
commandArgs: [<comma>, <separated>, <arguments>]

where each attribute is passed directly to podman run.

If we take as an example the podman run command:

podman --events-backend file run --env VAR=able docker.io/alpine:latest echo Hello!

it would translate to the following runtime configuration:

generalOptions: ["--events-backend", "file"]
image: docker.io/alpine:latest
commandOptions: ["--env", "VAR=able"]
commandArgs: ["echo", "Hello!"]

PodmanKubeRuntimeConfig

The runtime configuration for the podman-kube runtime is specified as follows:

generalOptions: [<comma>, <separated>, <options>]
playOptions: [<comma>, <separated>, <options>]
downOptions: [<comma>, <separated>, <options>]
manifest: <string containing the K8s manifest>

where each attribute is passed directly to podman play kube.

If we take as an example the podman play kube command:

podman --events-backend file play kube --userns host manifest.yaml

and the corresponding command for deleting the manifest file:

podman --events-backend file play kube manifest.yaml --down --force

they would translate to the following runtime configuration:

generalOptions: ["--events-backend", "file"]
playOptions: ["--userns", "host"]
downOptions: ["--force"]
manifest: <contents of manifest.yaml>
